Durable, heavy duty, finned cast iron construction

Oil-filled, hermetically-sealed motor with Class F insulation

Cutters protected from abrasive solids

Automatic thermal overload protection

Easily adapts to many existing competitors’ rail systems

Corrosion-resistant, powder coated epoxy finish

Dual mechanical shaft seals with leak detection – carbon/ceramic

Double shaft seal for added protection

Moisture detection and temperature protection

Made in USA

AMP	17.2
Impeller	Vortex
Volts	230V
VAC at 60 Hz	230
UL Listed	No
RPM	3450
Pump Phase	1
Pump Motor Type	Capacitor Start/Capacitor Run
Pump Body Material	Cast Iron
Pump Application	Residential
Power Source	Electric
Phase	Single Phase
Maximum Temperature	130
Maximum Feet of Head	125
Length	15 in
IAPMO Listed	No
Built-In Grinder	Yes
Horsepower	3 hp
Height	24-7/32 in
Flow Rate	59 gpm
End Connections	NPT
End Connection 2	NPT
End Connection 1	NPT
Discharge Configuration	Vertical
Discharge	1-1/4 in
Diameter	11-21/32 in
Cover Included	No
Cord Length	20 ft
Collection	841 Series
Coating	Epoxy
CSA Certified	CSA C22.2
Width	12 in
